EyeBeam Dome

EBdome-after

The EyeBeam Dome™ was developed to meet the requests of an interior dome light for all aircraft, that would complement the amazing Aveo EyeBeam™ products, and their unique capacitive touch-controls. Long gone are the days of mechanical switches which can corrode and spark, etc.

Features

Available in Visible White or NVIS Compatible White only

WIDE beam angle 130°

This light features a wide DIFFUSE white color that eliminates glare.

Touch control

Capacitive touch control works with your finger or even flight gloves. Can be controlled by separate extra wall remote mount.

Easy to install

Simple non-screw installation means low overhead space required.

Shockproof

Cockpit and cabin lighting, especially on aircraft, helicopters, boats, recreational vehicles and trucks are plagued by problems from vibration…. the EyeBeam overcomes this with a vibration-proof product.

3-Years warranty

3-years warranty of materials and workmanship.

Diameter: 63 mm / 2.48”
Weight: 80 g / 2.82 oz
Operating Voltage Range:

9 – 36 Vdc

Nominal Voltage: 12V or 24V
Current ( @12V): 0.2A (full brightness)
LED Color: Neutral White
Wide viewing angle 115°-130°

Installation Manual

Coming soon
